Technical characteristics
Overview
3-part DIFF analyzer with 21 parameters.
Measurement methods: impedance and colorimetry.
Cyanide-free reagents.
Specifications
Sample volume
14 µL (whole blood mode), 20 µL (pre-diluted mode).
Storage capacity
Stores up to 50,000 results with histograms.
Quality control
Levey-Jennings diagram, multiple quality control files.
Communication
1× network port, 1× RS-232 port, 4× USB ports; LIS connectivity supported.
Analytical performances
Repeatability (CV)
GB ≤ 2%
HGB ≤ 1.5%
MCV ≤ 0.5%
GR ≤ 1.5%
PLT ≤ 4%
